The 1EDCxxI12AH and 1EDCxxH12AH are galvanically isolated single channel IGBT driver in a PG-DSO-8-59 package that provide output currents up to 10 A at separated output pins.
The input logic pins operate on a wide input voltage range from 3 V to 15 V using scaled CMOS threshold levels to support even 3.3 V microcontrollers. Data transfer across the isolation barrier is realized by the coreless transformer technology. Every driver family member comes with logic input and driver output undervoltage lockout (UVLO) and active shutdown.
Industry: Industrial Automation
-
1EDC60I12AH
-
AD8051ARTZ
The AD8051 (single), AD8052 (dual) and AD8054 (quad) are low cost, high speed, voltage feedback amplifiers. The amplifiers operate on +3 V, +5 V or ±5 V supplies at low supply current. They have true single-supply capability with an input voltage range extending 200 mV below the negative rail and within 1 V of the positive rail.
Despite their low cost, the AD8051/AD8052/AD8054 provide excellent overall performance and versatility. The output voltage swings to within 25 mV of each rail, providing the maximum output dynamic range with excellent overdrive recovery.
The AD8051/AD8052/AD8054 are well suited for video electronics, cameras, video switchers, or any high speed portable equipment. Low distortion and fast settling make them ideal for active filter applications.
The AD8051/AD8052 in the 8-lead SOIC, the AD8052 in the MSOP, the AD8054 in the 14-lead SOIC, and the 14-lead TSSOP packages are available in the extended temperature range of −40°C to +125°C.
-
C2012X7S1E106K125AC
General type C series is a surface-mounted component, which multilayer dielectrics and inner electrodes are stacked alternately. The monolithic structure ensures superior mechanical strength and high reliability. Also, outstanding frequency characteristics such as low ESR and low ESL are provided owing to the simpler structure than other capacitors. The capacitance range is up to 100μF and the lineup has been expanding to a range of the film capacitor and electrolytic capacitor.
-
FDMF3035
The SPS family is onsemi’s next−generation, fully optimized,
ultra−compact, integrated MOSFET plus driver power stage solution
for high−current, high−frequency, synchronous buck, DC−DC
applications. The FDMF3035 integrates a driver IC with a bootstrap
Schottky diode and two power MOSFETs into a thermally enhanced,
ultra−compact 5 mm x 5 mm package.
With an integrated approach, the SPS switching power stage is
optimized for driver and MOSFET dynamic performance, minimized
system inductance, and power MOSFET RDS(ON). The SPS family
uses onsemi’s high−performance POWERTRENCH® MOSFET
technology, which reduces switch ringing, eliminating the need for a
snubber circuit in most buck converter applications.
A driver IC with reduced dead times and propagation delays further
enhances the performance. The FDMF3035 supports diode emulation
(using FCCM pin) for improved light−load efficiency. The
FDMF3035 also provides a 3−state 5 V PWM input for compatibility
with a wide range of PWM controllers. -
GD32F303VET6
GigaDevice, established in 2005, is a leading fabless
company engaged in advanced memory technology
and IC solutions. The company has successfully
completed the IPO at Shanghai Stock Exchange in
2016. GigaDevice provides a wide range of high
performance Flash memory and 32-bit generalpurpose MCU products. Gigadevice is among the
companies that pioneered SPI NOR Flash memory
and is currently ranked number three in the world in
this market segment with more than 1 billion units
shipped every year.
Since 2007, GigaDevice is ISO9001 and ISO14001
certified by SGS. GigaDevice has filed 600+ patent
applications with 200+ patents granted. More than
55% employees are in research and development,
which continues to differentiate our products
from competitions in the market. The GigaDevice
management team embodies leading semiconductor
industr y experience from renowned memor y
companies in California’s Silicon Valley, Korea, and
Taiwan. -
HIP4081AIBZ
The HIP4081A is a high frequency, medium voltage Full Bridge N-Channel FET driver IC, available in 20 lead plastic SOIC and DIP packages. The HIP4081A can drive every possible switch combination except those which would cause a shoot-through condition. The HIP4081A can switch at frequencies up to 1MHz and is well suited to driving Voice Coil Motors, high-frequency switching power amplifiers, and power supplies. For example, the HIP4081A can drive medium voltage brush motors, and two HIP4081As can be used to drive high performance stepper motors, since the short minimum “on-time” can provide fine micro-stepping capability. Short propagation delays of approximately 55ns maximizes control loop crossover frequencies and dead-times which can be adjusted to near zero to minimize distortion, resulting in rapid, precise control of the driven load. A similar part, the HIP4080A, includes an on-chip input
comparator to create a PWM signal from an external triangle wave and to facilitate “hysteresis mode” switching. The Application Note for the HIP4081A is the AN9405. -
i6A4W015A033V-001-R
The i6A4W series of non-isolated DC-DC step-down converters are ideal for creating additional high current output voltage rails from a single output 12V,
24V or 48V AC-DC or DC-DC power supply. The highly efficient i6A4W series accepts a very wide DC input and has a wide output adjustment range, with a
choice of 1/16th brick footprint or SIP package. Output trim, remote sense, negative or positive logic remote On-Off comes as standard features. Power good,
frequency synchronization and output sequencing are optional features. -
IR38060MTRPBF
The IR38060 PMBus SupIRBuck™ is an easy-to-use,
fully integrated and highly efficient DC/DC regulator
with I2C/PMBus interface. The onboard PWM controller
and MOSFETs make IR38060 a space-efficient
solution, providing accurate power delivery for low
output voltage and high current applications.
The IR38060 can be comprehensively configured via
PMBus and the configuration stored in internal
memory. In addition, PMBus commands allow run-time
control, fault status and telemetry.
The IR38060 can also operate as a standard analog
regulator without any programming and can provide
current and temperature telemetry in an analog format -
ISL8274MIRZ
The ISL8274M is a complete PMBus enabled DC/DC, dual-channel, step-down advance power supply, capable of delivering up to 30A per channel and optimized for high power density applications. Operating across an input voltage range of 4. 5V to 14V, the ISL8274M offers adjustable output voltages down to 0. 6V and achieves up to 95. 5% conversion efficiencies. A unique ChargeMode™ control architecture provides a single clock cycle response to an output load step and can support switching frequencies up to 1. 06MHz. The power module integrates all power and most passive components and requires only a few external components to operate. A set of optional external resistors allows the user to easily configure the device for standard operation. For advanced configurations, a standard PMBus interface addresses tasks such as sequencing and fault management, as well as real-time full telemetry and point-of-load monitoring. Additionally, the nonvolatile memory can store the desired custom configuration and settings. A fully customizable voltage, current, and temperature protection scheme ensures safe operation for the ISL8274M under abnormal operating conditions. The device is also supported by the PowerNavigator™ software, a full digital power train development environment. The ISL8274M is available in a low profile, compact 18mmx23mmx7. 5mm fully encapsulated, thermally enhanced HDA package.
-
MK22FN512VLH12 (Kinetis K22 MCU)
Performance
• 120 MHz Arm Cortex-M4 core with DSP instructions delivering 1.25 Dhrystone MIPS per MHzMemories and memory interfaces
• 512 KB of embedded flash and 128 KB of RAM
• FlexBus external bus interface 1
• Serial programming interface (EzPort)
• Preprogrammed Kinetis flashloader for one-time, insystem factory programming Timers
• Two 8-ch general purpose/PWM timers
• Two 2-ch general purpose timers with quadrature decoder functionality
• Periodic interrupt timers
• 16-bit low-power timer
• Real-time clock with independent power domain
• Programmable delay blockSecurity and integrity modules
• Hardware CRC module
• 128-bit unique identification (ID) number per chip
• Hardware random-number generator
• Flash access control to protect proprietary software
Operating Characteristics
• Voltage range (including flash writes): 1.71 to 3.6 V
• Temperature range (ambient): -40 to 105°C Analog modules
• Two 16-bit SAR ADCs (1.2 MS/s in 12bit mode)
• Two 12-bit DACs 2
• Two analog comparators (CMP) with 6-bit DAC
• Accurate internal voltage reference System peripherals
• Flexible low-power modes, multiple wake-up sources
• 16-channel DMA controller
• Independent external and software watchdog monitorClocks
• Two crystal oscillators: 32 kHz (RTC) and 32-40 kHz or 3-32 MHz
• Three internal oscillators: 32 kHz, 4 MHz, & 48 MHz
• Multipurpose clock generator with PLL and FLLCommunication interfaces
• USB full/low-speed On-the-Go controller
• USB full-speed device crystal-less operation
• Two SPI modules and I2S module
• Three UART modules and one low-power UART
• Two I2C: Support for up to 1 Mbps operationHuman-machine interface
• Up to 81 general-purpose I/O (GPIO) -
MK64FN1M0VLL12 (Kinetis K64 MCU)
120 MHz ARM® Cortex®-M4-based Microcontroller with FPU The K64 product family members are optimized for cost-sensitive applications requiring low-power, USB/Ethernet connectivity, and up to 256 KB of embedded SRAM. These devices share the comprehensive enablement and scalability of the Kinetis family.
This product offers:
• Run power consumption down to 250 μA/MHz. Static power consumption down to 5.8 μA with full state retention and 5 μs wakeup. Lowest Static mode down to 339 nA
• USB LS/FS OTG 2.0 with embedded 3.3 V, 120 mA LDO Vreg, with USB device crystal-less operation
• 10/100 Mbit/s Ethernet MAC with MII and RMII interfaces -
NCP3066DR2G
